2016 DYNAPAC FC16000
Year
2016
Hours
3,800
Horsepower
99 HP
Operating Weight
18,500 lbs
About this FC16000
2016 DYNAPAC FC16000 Mass (tractor) 14,000 lbs Paver weight (incl. standard screed) 18,500 lbs Dimensions Basic width 8 ft Working width, max. 18 ft Working width, hydraulic extendable 15.50 ft Working width, minimum (Cut Off Shoe) 1 ft Front ramp angle 11° Capacity Theoretical placement capacity 600 t/h Paving thickness (max/min) 6 in /0 in Material hopper Capacity 16,000 lbs Dumping height, center 21 in Hopper width, internal 120 in Propulsion Paving speed 0-140 fpm Transport speed 3 mph Engine Manufacturer/Model Cummins QSB 3.3 Emissions according to EPA T3/EU3A Rated power, SAE J1995 74 kW (99 hp ) @ 1400 rpm Electrical system 12V Fuel tank capacity 22 gal Engine alternator capacity 120 Amps Heating generator capacity 16 kW, 240V 1 phase Undercarriage Type Steel track with poly pad Crawler length 72.0 in Crawler width 12.0 in Final drive Hydrostatic with gear reducer Conveyor Conveyor type Dual slat conveyor Conveyor width 2 x 24 in Conveyor control Automatic with Auger control Auger Auger diameter 9 in Auger control Automatically with ultrasonic sensor Extension auger 9 inches, mounted on screed extensions. Financing Available.
- Cummins QSB 3.3 diesel engine, 99 hp
- EPA Tier 3 / EU Stage 3A emissions
- Max paving width 18 ft (hydraulic extendable to 15.5 ft)
- Theoretical placement capacity 600 t/h
- Steel tracks with poly pads
Auto-generated from manufacturer literature; please verify against the actual unit before relying on any spec. Source
Noted in the Description
- CUMMINS QSB 3.3 ENGINE
- 99 HP
Equipment & Attachments
- STEEL TRACKS WITH POLY PADS
Additional Notes
- TIER 3 EMISSIONS
- MAX PAVING WIDTH 18 FT
- HYDRAULIC EXTENDABLE SCREED
- 600 T/H CAPACITY
Specifications
Additional Specifications
About this Model
The 2016 Dynapac FC16000 is a robust tracked commercial paver designed for efficient asphalt paving in various road construction applications. It stands out with its advanced material handling system, precise paving controls, and durable undercarriage, making it a reliable choice for achieving high-quality road surfaces.
General information about the DYNAPAC FC16000 model line. Details for this specific unit are above.
