2017 HAMM H11IX
compactionHAMMAvailable
$39,750
Located in Texas
~10 miles from San Antonio
Year
2017
Hours
3,240
Horsepower
114 HP
Operating Weight
24,617 lbs
Item # PE-45945Stock # JSA1Ox0U958141
About this H11IX
2017 Hamm H 11ix vibratory smooth drum roller. Powered by a 114 hp (85 kW) Deutz TCD 3.6 L4 diesel engine meeting EU Stage V / EPA Tier 4 emission standards with DOC-DPF-SCR after-treatment. This 24,617 lb. single-drum compactor features a 2.14 m (84.3 in) smooth drum with dual amplitude (2.04 mm / 0.84 mm) and dual vibration frequency (30/36 Hz). Seller notes a slight hydraulic leak.
- DEUTZ TCD 3.6 L4 diesel, 113.9 HP
- EU Stage V / EPA Tier 4 Final
- Smooth drum, 84.3 in wide
- Dual amplitude / dual frequency vibration
- Hammtronic all-wheel drive & traction control
Auto-generated from manufacturer literature; please verify against the actual unit before relying on any spec. Source
Noted in the Description
- 113.9 HP DEUTZ DIESEL
Additional Notes
- TIER 4 FINAL
- SMOOTH DRUM
- 84.3 IN DRUM WIDTH
- ARTICULATED STEERING
Specifications
Horsepower114 HP
Operating Weight24,617 lbs
EngineDeutz TCD 3.6 L4
EmissionsTier 4 Final / EU Stage V
Fuel Capacity74 gal
Configuration
Tire SizeAW 23.1-26 12 PR
Additional Specifications
Drum TypeSmooth
Drum Width84.3 in
Drum Diameter59.2 in
Compaction Width84.3 in
Centrifugal Force55,350 lbf
Amplitude0.08 in
Vibratory / StaticVibratory
